Getting a flange connection right is what separates a professional, safe piping system from one that leaks and fails. At FlangesSteel.com, we’ve supplied flange steel products for countless projects across the USA. We know that a successful installation starts with knowledge.
This guide will walk you through how to properly “flange out” a stainless steel pipe. We’ll use simple language and clear steps, drawing on industry best practices we trust every day.
What You Need to Know Before You Start
“Flanging out” simply means permanently attaching a steel pipe flange to the end of a pipe. This creates a strong, boltable connection point. For stainless steel, the two most common types are Weld Neck and Slip-On flanges.
You might be wondering which one to choose. A Weld Neck flange is the go-to for high-pressure or high-temperature services because of its superior strength. A Slip-On flange is easier to align and is suitable for many general applications. If you’re unsure, Texas Flange has a detailed guide that explains all the different flange types and their uses.
Tools and Materials You Will Need
Gathering the right tools is the first step to a quality job. Here’s what you’ll need:
Stainless Steel Pipe & Flange: Ensure the flange material is compatible.
Tools: Pipe cutter/beveler, TIG welder, clamps, torque wrench, wire brush (for stainless only), square, cleaning rags.
Consumables: Acetone for cleaning, correct filler wire (like ER308L/ER316L), a gasket, and bolts/nuts.
Safety Gear: Welding helmet, gloves, and a fire-resistant jacket are essential.
A quick tip: While we’re focusing on stainless steel, many projects successfully pair it with a carbon steel flange for non-corrosive sections to manage costs. The key is to match the material to the service environment.
Step 1: Prepare the Pipe and Flange
This is the most critical phase. Poor preparation guarantees problems later.
Cut the Pipe Square: Use a quality cutter. The pipe end must be perfectly square for a flush fit with the flange.
Bevel the Pipe End: For a Weld Neck flange, you must create a 37.5-degree bevel. This groove is vital for a strong, full-penetration weld. Slip-On flanges typically don’t need this.
Clean Everything Meticulously: Use a stainless-steel-only wire brush on the pipe end and the flange interior. Then, wipe all surfaces with acetone. This removes oils and dirt.
One thing to consider: Never use a carbon steel brush on stainless steel. It will implant tiny carbon steel particles, causing the stainless to rust later.
Step 2: Align and Tack Weld the Flange
Precision here makes final assembly straightforward.
Position the Flange: Slide on a Slip-On or align a Weld Neck flang
Check for Square: Place a square against the face of the steel flange plate. It must be perfectly perpendicular to the pipe. A small misalignment here makes bolting the flanges together nearly impossible.
Tack Weld in Place: Use three or four small tack welds, spaced evenly around the pipe, to hold the flange securely.
Step 3: Weld the Flange to the Pipe
This step requires skill. If you are not a certified welder, it’s best to partner with one.
Use a TIG welder for the best control and a clean weld on stainless steel.
Weld around the entire circumference, filling the bevel for a Weld Neck or making the hub and inside fillet welds for a Slip-On.
Control your heat. Too much heat can warp the flange and damage the corrosion resistance of the stainless steel.
Step 4: Clean the Weld Area
After welding, you’ll see a colorful heat tint (blue, purple hues). This area has a weakened corrosion barrier and must be cleaned.
Let the assembly cool naturally.
Apply a stainless steel pickling paste to the welded area to restore the protective layer. Follow the product instructions, then rinse and dry thoroughly.
Step 5: Assemble the Flanged Joint
Your flanged pipe is ready for its final connection.
Center the correct gasket between the two flange faces.
Bring the flanges together, align the bolt holes, and insert the bolts.
Hand-tighten the nuts.
Using a torque wrench, tighten the bolts in a cross-pattern (like tightening a car tire). Do this in several stages (e.g., 30%, 70%, 100% of final torque) to compress the gasket evenly.
For specific bolt torque values, which depend on size and grade, consult the technical data available from Texas Flange. This ensures your assembly meets industry standards.
Frequently Asked Questions
Can I use a threaded flange on stainless steel pipe?
Yes, but only for low-pressure, non-critical applications. A welded connection, like a Weld Neck or Slip-On, is far stronger and more reliable for most industrial systems where safety is a priority.
Why is my stainless steel rusting near the weld?
This is almost always caused by cross-contamination. You likely used a carbon steel tool, like a wire brush or hammer, on the stainless steel. Always use tools dedicated solely to stainless steel work.
What’s the difference between a stainless and carbon steel flange?
The main difference is corrosion resistance. Stainless steel flanges contain chromium, which protects against rust, making them ideal for corrosive or clean services. A carbon steel flange is strong and cost-effective but will rust if not protected, so it’s used for oil, gas, or water in non-corrosive environments.
How tight should I make the flange bolts?
There is no single answer. The final torque value depends on the bolt size, grade, and gasket type. You must consult an ASME-based torque chart. Guessing can lead to broken bolts or a leaky connection.
Do you provide material certifications with your flanges?
Yes, we do. At FlangesSteel.com, we provide full traceability. Our flanges come with certified Mill Test Reports (MTRs) that verify the material grade, dimensions, and chemical composition, so you can be confident in the quality of the flange steel you’re installing.
